    W-Shaped Cr12 Steel Sheet Metal Roll Forming Machines ISO Certification

    Ask Lasest Price
    Brand Name : HC
    Certification : CE
    Model Number : HC330
    Price : 29000-49000USD
    Delivery Time : 60days after receive agreed deposit.
    Payment Terms : 30% deposit by TT in advance, the balance to be paid before delivery.
    Supply Ability : 20Set/Month
    • Product Details
    • Company Profile

    W-Shaped Cr12 Steel Sheet Metal Roll Forming Machines ISO Certification

    W Shaped Auto Cr12 Steel Sheet Metal Roll Forming Machines ISO Certification


    Quick Detail:

    1. Suitable to process: Color steel plate

    2. Width of the plate: 550mm

    3. Rollers: 24 rows

    4. Dimensions: 11.6*1.35*1.51m

    5. Power: 22+7.5kw

    6. Rolling material: shaft bearing steel(quenching)

    7. Thickness of the plate:2.5-3mm

    8. Voltage: 380V 50Hz 3phases

    9. Material of the cutting plate: Cr12

    10. Hydraulic: 40#

    11. Processing precision: Within 1.00mm

    12. Control system: PLC control


    5,Description:


    Highway Guardrail R Forming Machine Main parameter

    No.

    Main parameter of Highway Guardrail R Forming Machine

    1

    Suitable to process

    Color steel plate

    2

    Width of the plate

    550mm

    3

    Rollers

    24 rows

    4

    Dimensions

    110600*1350*1510mm

    5

    Power

    33+7.5kw

    6

    Rolling material

    shaft bearing steel(quenching)

    6

    Thickness of the plate

    2.5-3mm

    7

    Productivity

    8-10m/min

    8

    Diameter of the roller

    Φ100mm

    9

    Voltage

    380V 50Hz 3phases

    10

    Material of the cutting plate

    Cr12

    11

    Hydraulic

    40#

    12

    Processing precision

    Within 1.00mm

    13

    Control system

    PLC control

    Equipment components: Man-made uncoiler-leveling-roll forming machine-computer control system-hydraulic control system-punching-cutting


    Competitive Advantage


    1. ISO certification

    2. CE certification

    3. PLC Panasonic

    4. One year free warranty

    5. Low loss, easy operate
