    Metal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm Thickness

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC80-300
    Certification : ISO
    Price :
    Payment Terms : 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
    Supply Ability : 20 sets/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    Metal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm Thickness

    Metal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm Thickness

    Introduction:

    The C and Z purline forming line has advantage of automatic fixed-length cutting automatic punching. Besides, its installation is convenient having high level automation. The purline produced by this machine has the feature of bending and pressing resistance with high level glancing flatness. This kind of products is mainly used for large and medium industrial or civil architecture including factories, storage locomotive sheds and aero plane sheds stadium, exhibition and Movie Theater and free market. Cold forming sectional steel is main material to produce light section steel structure produced by steel plate and cold forming sectional steel. The machine can produce variety kinds of profiles and cold rolled steels with regular thickness, but in complex section shape. Those products can not produced by general heat rolling method.

    The products of C or Z shape purline forming machine have excellent anti-bending property and are
    easy to install. They are widely used as the supporter of roof and wall in large-scale and mid-scale
    construction, such as factory, warehouse, garage, exhibition center, cinema, theatre, garden and so on.

    Metal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm ThicknessMetal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm ThicknessMetal Interchangeable C Purlin Roll Forming Machine , Roll Form Machine 1.5-3.0mm Thickness


    Main specification:

    MATERIAL:

    Suitable Coil Thickness2.0-3.0 mm
    Suitable Raw MaterialsQ235 A

    MACHINE COMPONENTS:

    Manual Un-coiler1 set
    Leveling Device1 set
    Roll-Forming M/C1 set
    Hydraulic cutting (with four cutting mould)1 set
    PLC Control System1 set
    Product rack (un-powered)1 set

    Working Flow:
    Decoiling the Sheet—Sheet Guiding —Coil Strip Leveling—Roll Forming—Punching for
    horizontal hole—Punching for vertical hole —Measure Length —Cutting the Panel—Panels to the Supporter.


    Advantage:

    1. We use Automatic control software to manage productive information.

    2. Thanks to the High integrated network, the whole automatic control system has an improvement in automaticity.

    3. High performance in operation, maintenance, and debugging. Easy to load and unload.

    4. First in quality

    5. First in time

    6. First in price

    7. First in services
