    Carry Channel U38x12 Roll Forming Machine

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC C/U
    Certification : ISO
    Price : 19500USD
    Payment Terms : 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
    Supply Ability : 20 sets/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    Carry Channel U38x12 Roll Forming Machine

    Quick Detail:

    1. Suitable to process: Color steel plate

    2. Width of the plate: C100mm U61mm

    3. Rollers: 11rows

    4. Dimensions: 6.1*1.15*1.51m

    5. Power: 7.5+4+1.KW

    6. Rolling material: shaft bearing steel(quenching)

    7. Thickness of the plate:0.3-0.6mm

    8. Voltage: 380V 50Hz 3phases

    9. Material of the cutting plate: Cr12

    10. Hydraulic: 40#

    11. Processing precision: Within 1.00mm

    12. Control system: PLC control


    Description:

    Keel Roll Forming Machine Main parameter

    No.

    Main parameter of Keel Roll Forming Machine

    1

    Suitable to process

    Color steel plate

    2

    Width of the plate

    C100mm U61mm

    3

    Rollers

    11rows

    4

    Dimensions

    6100*1150*1510mm

    5

    Power

    7.5+4+1.KW

    6

    Rolling material

    shaft bearing steel(quenching)

    7

    Thickness of the plate

    0.3-0.6 mm

    8

    Productivity

    20m/min

    9

    Diameter of the roller

    Φ50mm

    10

    Voltage

    380V 50Hz 3phases

    11

    Material of the cutting plate

    Cr12

    12

    Hydraulic

    40#

    13

    Processing precision

    Within 1.00mm

    14

    Control system

    PLC control

    Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting

    Competitive Advantage

    1. ISO/CE certification

    2. 20sets/ month

    3. high-speed production

    4. easy operate, easy maintain

    5.One year free warranty
