    New Design Metal Silo Double Deck Roll Forming Machine

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC25-70-1000-1250
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    New Design Metal Silo Double Deck Roll Forming Machine

    Product Description
    In modern industrial construction, industrial plants are important spaces for various production activities and are usually large in scale. The roof area is vast and the demand for roofing materials is considerable. The double-layer tile pressing machine has its advantages in such scenarios. Its unique double-layer design can produce two tiles of different specifications at the same time.

    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1250mm
    Roller Stations18Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    In the production process of the tile press, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unfold these tightly wound metal sheets.


    Hydraulic Pump Station

    The hydraulic pump station converts mechanical energy into stable and powerful hydraulic energy through precise oil pump components, providing power support for multiple key components of the tile press. It drives the roller to operate smoothly and applies continuous and controllable pressure to the roller during the forming stage of tiles such as colored steel tiles or glazed tiles.


    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.

    Feeding Table & Pre-Cutter


    The feed table is usually equipped with conveying devices, such as conveyor rollers, conveyor belts, etc., which can slowly and steadily convey the plates from one end of the feed table to the entrance of the tile press.


    Shaft & Roller

    Rollers are the core components for shaping metal sheets into glazed tiles. In the initial stage of production, similar to the leveling process of the floor deck forming machine, rollers will perform preliminary processing on the unfolded metal sheets. By applying reasonable pressure and repeatedly rolling the sheets, the unevenness of the sheets during transportation or storage is eliminated, so that they reach a flatness suitable for subsequent fine processing.


    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.


    This not only improves construction efficiency, but also ensures that the size of the tiles perfectly matches the actual needs of the building, greatly speeding up the construction progress of the entire construction project and ensuring that the project is completed on time.
