    China Glazed Tile Roll Forming Machine

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC28-107-828-1000-1200
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    China Glazed Tile Roll Forming Machine

    Product Description
    The glazed tile pressing machine adopts an automated production process and has a fast operating speed, and can produce a large number of glazed tiles in a short time. Compared with traditional manual production or other relatively backward production methods, it greatly improves production efficiency and can meet the needs of large-scale construction projects.

    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1250mm
    Roller Stations12Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed4m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    In the production process of glazed tiles, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.


    Hydraulic Pump Station

    When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.


    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.


    Feeding Table & Pre-Cutter

    The feeding table can provide stable support for the plates, especially for some larger, thinner or heavier plates. The feeding table can prevent the plates from bending, deforming or sagging during the feeding process.



    Shaft & Roller

    The shaft is the supporting base of the roller, which keeps the roller in the correct position and posture to ensure that it can stably press and shape the plate. Multiple groups of rollers are installed on the frame of the tile press through the shaft. The accuracy and strength of the shaft directly affect the concentricity and stability of the roller, and thus affect the forming quality of the glazed tile.

    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.

    The fast and accurate cutting function enables the production of glazed tiles to be continuous and automated, eliminating the need for tedious manual measurement and cutting operations, greatly improving production efficiency and reducing production time and labor costs.
