Product Description
The double-layer tile pressing machine can produce two different
specifications of tiles at the same time with its efficient
production capacity, greatly shortening the production cycle and
meeting the needs of rapid construction of industrial plants.
Moreover, the tiles it produces are of reliable quality, with high
dimensional accuracy after precise molding process, which can
provide stable and durable roof covering for industrial plants and
adapt to various climate and mechanical stresses that may be faced
in industrial environments.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm |
| Width | 915mm |
| Roller Stations | 12/13Stations |
| Roller & Shaft Material | 45# Steel Quenching and Plating |
| Diameter of Shaft | Φ70mm |
| Cutter Material | CR12 |
| Drive Type | Chain Drive |
| Speed | 15m/min |
| Total Power | 5.5+5.5KW |
| Voltage | 380V 50Hz 3Phases |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
Uncoilers play an indispensable role in the production process of
tile presses. In the production process of tile presses, metal
sheets are usually supplied in the form of coils, and the primary
function of the uncoiler is to smoothly and steadily unwind these
tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive
pressure, it can automatically adjust the pressure of the hydraulic
system to avoid damage to the equipment due to overload
During the cutting process, the hydraulic pump station pushes the
cutting tool to move quickly and powerfully, accurately cutting the
formed floor decking according to the set length.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Users can store the production programs of floor decking boards of
different specifications in the control cabinet. The next time they
produce products of the same specifications, they can directly call
them without resetting parameters, which greatly improves
production efficiency.
Feeding Table & Pre-Cutter
The temporary loading platform after the metal coil is unwound
ensures that the plates output from the uncoiler can be placed in
an orderly manner to avoid plate accumulation and folding during
the transition process.
Shaft & Roller
In the leveling stage, the leveling rollers apply appropriate
pressure to repeatedly roll the uneven plates to eliminate the wavy
and curved defects on the plate surface, so that the plate can
reach the flatness required for subsequent forming. In the forming
stage, a series of forming rollers of different shapes and
specifications gradually cold-bend the plate in sequence.
Pressing Section & Cutter
The reliability and durability of the cutter are also important
factors affecting production stability. Carefully designed and
manufactured cutters can maintain good cutting performance in
long-term, high-intensity working environments, reducing the
frequency of downtime and replacement due to cutter wear and
damage, thereby reducing production costs and improving the
company's production efficiency.
