    High Speed Step Tile Roof Roll Forming Machinery

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC-32-195-1220
    Certification : CE
    Payment Terms : L/C,T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    High Speed Step Tile Roof Roll Forming Machinery

    Product Description

    The equipment has precise forming molds and advanced pressing technology, which can ensure that the pressed trapezoidal corrugated board has high dimensional accuracy, regular shape and smooth surface. At the same time, it can also effectively control the height, spacing and other parameters of the corrugation, making the product quality stable and reliable, meeting the high standards of the construction industry.

    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1220mm
    Roller Stations15Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.


    Hydraulic Pump Station

    When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.


    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.

    Feeding Table & Pre-Cutter

    The feed table can be used as a temporary buffer and storage area, and can play a certain buffering role when the board supply speed is not completely consistent with the production speed of the tile press. For example, when the board supply is fast, the feed table can temporarily store some boards to avoid affecting the production process due to the accumulation of boards


    Shaft & Roller

    The wheels of the tile press usually refer to the forming rollers, which are the direct acting parts for processing the plate into trapezoidal tiles. The surface shape of these rollers is precisely processed according to the design requirements of the trapezoidal tiles. Through the gradual rolling of multiple rollers, the flat plate is gradually bent into the shape of a trapezoidal tile.


    Pressing Section & Cutter
    Fast and efficient cutting action can reduce the production time of a single tile, thereby improving the production efficiency of the entire tile press. The cutting speed of the cutter can usually be adjusted according to the operating speed of the tile press and the material of the board to achieve the best production rhythm.
