Brand Name : | Huachen |
Model Number : | HC93-245 |
Certification : | CE |
Price : | Negotiation between the two parties |
Payment Terms : | T/T |
Supply Ability : | 20set per month |
Delivery Time : | 45days |
Product Description
When selecting the right ridge tile machine for your manufacturing needs, consider the following factors:
1. Production Capacity
Determine the volume of tiles you need to produce daily. Machines
vary in capacity, so choose one that meets your production goals.
2. Tile Specifications
Identify the types of ridge tiles you plan to manufacture (e.g.,
size, shape, material). Ensure the machine can handle these
specifications.
3. Automation Level
Decide between manual, semi-automatic, or fully automatic machines.
Fully automated options offer higher efficiency but may require a
larger investment.
4. Material Compatibility
Ensure the machine can work with the materials you plan to use
(e.g., concrete, clay). Different machines are designed for
different materials.
5. Quality and Durability
Research the build quality and durability of the machine. Look for
machines with a good reputation for reliability and longevity.
Product Parameter
Material | Type | PPGI/GI |
Thickness | 0.3-0.6mm | |
Width | 500mm | |
Roller Station | 11Stations | |
Roller & Shaft Material | 45# Steel Quenching and Plating | |
Diameter of Shaft | Φ70mm | |
Cutter Material | CR12 | |
Drive Type | Chain Drive | |
Maximum Forming Speed | 15m/min | |
Control System | PLC Control | |
Total Power | 4+4KW | |
Voltage | 380V 50Hz 3Phases |
NO. | NAME |
1 | Single layer roll forming machine |
2 | Duoble layer roll forming machine |
3 | Trapezoidal roll forming machine |
4 | Glazed tile roll forming machine |
5 | Currugated roll forming machine |
6 | Floor deck roll forming machine |
7 | Roll shutter door forming machine |
8 | C/Z/Uprofile steel forming machine |
9 | Ridge cap roll forming machine |
10 | Downspout forming machine |
11 | Keel roll forming machine |
12 | Heat retaining sandwich panel |
13 | Highway guardrail roll forming machine |
14 | Carrige board roll forming machine |
15 | High-frequency pipe welder |
16 | Hydraulic full-automatic decoiler and accessory equipments |
17 | Color steel roll forming machine |
18 | Joint-hidden type forming machine |
19 | Colorfull stone-coated steel |
20 | No-girder arched roll forming machine |
21 | Standing seam arching machine |
22 | Hydraulic crimping curving machine |
23 | Steel coil slitting roll forming machine |
24 | Windshield dust-controlling board producing line |
25 | Some others can be made on request |
Why Book With Us?
1.We have 20 years of experience in production and sales of tile
presses
2.We know the commonly used tile types in each region and can
recommend them to customers
3.We have an excellent design and production team that can design
and manufacture according to customer needs.
4.We have our own company and welcome customers at any time
5.We can help you contact the shipping company and we can also
deliver to your door if you need.
![]() |
