    380v Roof Steel Plate Glazed Tile Roll Forming Machine with CR12 Cutter Material

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC28-200-1000
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    380v Roof Steel Plate Glazed Tile Roll Forming Machine with CR12 Cutter Material

    Product Description

    Construction industry: widely used in roof and wall decoration of various industrial and civil buildings, such as factories, warehouses, houses, villas, gymnasiums, exhibition halls, theaters, etc., which can not only play the role of waterproofing and heat insulation, but also increase the beauty and artistic value of the building.
    Antique building restoration and new construction: In the restoration and new construction of antique buildings, the colored steel glazed tiles produced by the glazed tile press can replace the traditional ceramic glazed tiles, retain the style and charm of ancient buildings, and solve the problems of traditional glazed tiles being fragile, easy to fade, and high maintenance costs.
    Garden landscape architecture: used for the roof decoration of pavilions, corridors, archways and other garden landscape buildings in parks, squares, scenic spots and other places, creating an antique atmosphere and complementing the natural environment.


    Working Flow

    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Main Technical Parameters


    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1000mm
    Roller Stations12Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed2-4m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    5T Manual Decoiler

    This part is used to support Coil.

    And make the coil in a rotary way.

    Bearing capacity: 5T

    Inner diameter: 470-530mm

    (adjustable according to demand.)

    In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.


    Shaft & Roller


    Material is 45# Steel Quenching and Plating.

    The processed rollers are smooth, hard and will not rust.

    Will not leave any scratches on the sheet when working.


    Feeding Table & Pre-Cutter


    Guide the coil come into the correct position and going to the roll forming part.

    Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.


    Pressing Section & Cutter


    The material of blade is CR12.

    With high strength, better hardenability and good wear resistance.


    Hydraulic Pump Station

    The purpose of this pump station is to drive the cutter to start cutting works.

    The hydraulic tank use 46# hydraulic oil.

    Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

    Solenoid valve brand: Huade


    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.

    The unit length of the targeted sheet and quantity can be set in the touchscreen.

    The system is simple and easy to operate.

    Electrical Component Brand:

    1. VFD: Delta

    2. Circuit breaker: Delixi

    3. Contactor: Delixi

    4. Relay: Xinling

    5. PLC: Delta

    6. Transformer: Delixi


    Why Book With Us?

    1.We have 20 years of experience in production and sales of tile presses
    2.We know the commonly used tile types in each region and can recommend them to customers
    3.We have an excellent design and production team that can design and manufacture according to customer needs.
    4.We have our own company and welcome customers at any time
    5.We can help you contact the shipping company and we can also deliver to your door if you need.
