PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage

    Buy cheap PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage from wholesalers

    Buy cheap PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage from wholesalers
    • Buy cheap PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage from wholesalers

    PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC12-16-1000
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage

    Product Description


    A dual-purpose machine can produce two types of color steel tiles at the same time. Compared with the traditional single-layer tile press, the output is greatly increased, the production efficiency is significantly improved, and the production cycle is shortened.


    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1250mm
    Roller Stations12/16Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow

    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters

    Decoiler: This component unwinds the metal coil, which is typically made of steel or aluminum, and feeds it into the machine.


    Hydraulic Pump Station


    The purpose of this pump station is to drive the cutter to start cutting works.

    The hydraulic tank use 46# hydraulic oil.

    Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

    Solenoid valve brand: Huade


    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.

    The unit length of the targeted sheet and quantity can be set in the touchscreen.

    The system is simple and easy to operate.

    Electrical Component Brand:

    1. VFD: Delta

    2. Circuit breaker: Delixi

    3. Contactor: Delixi

    4. Relay: Xinling

    5. PLC: Delta

    6. Transformer: Delixi


    Shaft & Roller



    Roll Forming Machine: The heart of the system, this machine shapes the metal into the desired profile or slat design. Roll forming involves passing the metal through a series of rollers, each with a specific contour to gradually shape the material.


    Pressing Section & Cutter


    The material of blade is CR12.

    With high strength, better hardenability and good wear resistance.


    Before buying, consult different suppliers for prices, and be aware that equipment with too low a price may have quality problems. Compare the prices of double-layer tile pressing machines of different brands and configurations, and make a choice based on your budget and requirements for equipment performance.​


    Why Book With Us?

    1.We have 20 years of experience in production and sales of tile presses
    2.We know the commonly used tile types in each region and can recommend them to customers
    3.We have an excellent design and production team that can design and manufacture according to customer needs.
    4.We have our own company and welcome customers at any time
    5.We can help you contact the shipping company and we can also deliver to your door if you need.
