Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need

    Buy cheap Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need from wholesalers

    Buy cheap Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need from wholesalers
    • Buy cheap Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need from wholesalers

    Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC21-23-1220
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    Flexible Double Deck Roll Forming Machine with 5.5 5.5KW Total Power and CR12 Cutter Material for Customized Production Need

    Product Description


    The whole process is precisely controlled by the control system. The operator inputs various production parameters through the control system, such as plate thickness, tile size, cutting length, etc. The control system monitors and adjusts the operating status of each part of the equipment in real time according to these parameters to ensure the stability of the production process and the consistency of product quality.


    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1220mm
    Roller Stations12/13Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed4m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters

    Double Deck Roll Forming Machine Manufacturers 0


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm
    (adjustable according to demand.)
    In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

    Hydraulic Pump Station
    Double Deck Roll Forming Machine Manufacturers 1

    The purpose of this pump station is to drive the cutter to start cutting works.
    The hydraulic tank use 46# hydraulic oil.
    Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.
    Solenoid valve brand: Huade

    Touch Screen Control Cabinet

    Double Deck Roll Forming Machine Manufacturers 2

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.
    Electrical Component Brand:
    1. VFD: Delta
    2. Circuit breaker: Delixi
    3. Contactor: Delixi
    4. Relay: Xinling
    5. PLC: Delta
    6. Transformer: Delixi

    Feeding Table & Pre-Cutter


    Guide the coil come into the correct position and going to the roll forming part.

    Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.


    Shaft & Roller


    Material is 45# Steel Quenching and Plating.

    The processed rollers are smooth, hard and will not rust.

    Will not leave any scratches on the sheet when working.


    Pressing Section & Cutter


    The material of blade is CR12.

    After shaping, the metal is cut into individual slats of the required length. Precision cutting ensures uniformity in the final product.


    With this working principle, the double-layer glazed tile pressing machine can efficiently and accurately produce a large number of high-quality glazed tiles to meet the growing demand for glazed tiles in the construction industry.
