Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed

    Buy cheap Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed from wholesalers

    Buy cheap Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed from wholesalers
    • Buy cheap Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed from wholesalers

    Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC51-180-1105-1220
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    Efficient Roof Panel Roll Forming Machine Roofing Sheet Making Machine With 15m/min Speed

    Product Description

    The construction of various industrial plants is inseparable from floor decking. The floor decking produced by the floor decking forming machine has good load-bearing capacity and stability, and can adapt to the placement of heavy equipment and frequent production activities inside industrial plants.


    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.8-1.2mm
    Width1220mm
    Roller Stations27Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ90mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Control SystemPLC Control
    Total Power11+11+7.5KW
    Voltage380V 50Hz 3Phases

    Working Flow

    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

    Component & Technical Parameters

    Steel Deck Roll Forming Machine Xiamen Machine Floor Tile Decking Making Machine 0


    his part is used to support Coil.

    And make the coil in a rotary way.

    Bearing capacity: 5T

    Inner diameter: 470-530mm

    (adjustable according to demand.)

    In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.


    Hydraulic Pump Station

    Steel Deck Roll Forming Machine Xiamen Machine Floor Tile Decking Making Machine 1


    The purpose of this pump station is to drive the cutter to start cutting works.

    The hydraulic tank use 46# hydraulic oil.

    Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.


    Touch Screen Control Cabinet

    Steel Deck Roll Forming Machine Xiamen Machine Floor Tile Decking Making Machine 2


    The control cabinet has two modes, automatic and manual modes.

    The unit length of the targeted sheet and quantity can be set in the touchscreen.

    The system is simple and easy to operate.


    Output Table

    Steel Deck Roll Forming Machine Xiamen Machine Floor Tile Decking Making Machine 3

    This part is used to collect the formed products.

    The bracket is equipped with rollers to facilitate the product forwarding without being scratched.


    Feeding Table


    Guide the coil come into the correct position and passed to the roll forming machine.


    Shaft & Roller


    Material is 45# Steel Quenching and Plating.

    The processed rollers are smooth, hard and will not rust.

    Will not leave any scratches on the sheet when working.


    Cutter


    The material of blade is CR12.

    With high strength, better hardenability and good wear resistance.


    In high-rise residential buildings, floor decking, as an important part of the floor structure, can effectively improve the overall strength and earthquake resistance of the building.
