    Chain Drive Glazed Tile Forming Machine 380v 50Hz 3 Phases

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC34-151-908-1220
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    Chain Drive Glazed Tile Forming Machine 380v 50Hz 3 Phases

    Product Description
    The glazed tile pressing machine is a professional equipment designed specifically for the production of glazed tiles. It integrates advanced mechanical manufacturing technology and automatic control technology, and can accurately process metal coils, such as galvanized steel plates, color-coated steel plates, etc., into new color-coated steel glazed tiles with the appearance and performance of traditional glazed tiles.

    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1220mm
    Roller Stations26Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed4m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    Able to accommodate a variety of metal coils of different specifications, including different widths, thicknesses and materials​

    Hydraulic Pump Station

    When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.


    The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.
    Feeding Table & Pre-Cutter

    The feeding table also has a certain buffering function. When there is a short speed fluctuation in the upstream uncoiler or downstream forming equipment, the feeding table can maintain the continuity of material transportation through its own buffering mechanism to avoid production stagnation or sheet damage caused by speed differences.

    Shaft & Roller


    Material is 45# Steel Quenching and Plating.
    The processed rollers are smooth, hard and will not rust.
    Will not leave any scratches on the sheet when working.

    Inside the molding machine, multiple shafts cooperate with each other to support the rollers and other components, ensuring that they maintain a stable position and posture during operation.
    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.

    The reliability and durability of the cutter are also important factors affecting production stability. Carefully designed and manufactured cutters can maintain good cutting performance in long-term, high-intensity working environments, reducing the frequency of downtime and replacement due to cutter wear and damage, thereby reducing production costs and improving the company's production efficiency.

    This equipment not only retains the beautiful and elegant characteristics of traditional glazed tiles, but also gives the product many advantages of modern metal materials. It is widely used in various construction projects that pursue beauty and quality, adding unique charm to building roofs and walls.
