    Steel Tile Roof Roll Forming Machine / Metal Roofing Machine For Sale

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC35-333-1000
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    Steel Tile Roof Roll Forming Machine / Metal Roofing Machine For Sale

    Product Description

    Color steel tile forming machine is a mechanical equipment specially used for producing color steel tiles. It combines advanced mechanical manufacturing technology with automation control concepts, and can transform various metal coils, such as galvanized steel plates, color-coated steel plates, etc., into color steel tiles with various shapes and complete specifications through a series of process processing. This equipment is widely used in various construction fields, providing high-quality materials for covering building roofs and walls.


    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1000mm
    Roller Stations17Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm
    (adjustable according to demand.)
    In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

    In the production process, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.

    Hydraulic Pump Station


    The purpose of this pump station is to drive the cutter to start cutting works.
    The hydraulic tank use 46# hydraulic oil.
    Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

    It generates stable and controllable hydraulic pressure to drive the pressing rollers, cutting devices and other actions.

    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.
    Electrical Component Brand:
    1. VFD: Delta
    2. Circuit breaker: Delixi
    3. Contactor: Delixi
    4. Relay: Xinling
    5. PLC: Delta
    6. Transformer: Delixi

    Feeding Table & Pre-Cutter

    Guide the coil come into the correct position and going to the roll forming part.
    In the conveying process, the feeding table accurately controls the conveying speed and position of the plate, and works closely with the subsequent leveling device, forming equipment, etc. It feeds the plate into the leveling process at a stable speed, ensuring that the plate is in good conveying condition before being leveled, laying the foundation for high-quality leveling operations.
    Shaft & Roller

    Material is 45# Steel Quenching and Plating.
    The processed rollers are smooth, hard and will not rust.
    Will not leave any scratches on the sheet when working.

    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.

    The reliability and durability of the cutter are also important factors affecting production stability.
