Product Description

Equipped with advanced CNC systems and precision molds, it can accurately control the dimensional tolerance of the floor decking, ensuring that the wave height, spacing and flatness meet industry standards. This makes the floor decking dimensional accuracy high and the splicing tight, effectively improving the quality and efficiency of building construction.

Main Technical Parameters

Working Flow

Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

It can adapt to various metal coils of different specifications, including different widths, thicknesses and materials. Whether it is a thinner galvanized steel sheet or a thicker color-coated steel sheet, the uncoiler can smoothly unfold it through the corresponding adjustment mechanism to meet the diversified needs of floor decking production.

Hydraulic Pump Station

The purpose of this pump station is to drive the cutter to start cutting works.

The hydraulic tank use 46# hydraulic oil.

Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

Touch Screen Control Cabinet

In terms of production process monitoring, the touch screen control cabinet provides real-time feedback on the operating status of the equipment, such as the operating speed of each component, the pressure value of the hydraulic pump station, the working current of the motor, etc. The information is clearly displayed on the screen.

Output Table

This part is used to collect the formed products.

The bracket is equipped with rollers to facilitate the product forwarding without being scratched.

Feeding Table

When there is a short speed fluctuation in the upstream unwinder or downstream forming equipment, the feeder can maintain the continuity of material transportation through its own buffer mechanism to avoid production stagnation or sheet damage caused by speed differences.

Shaft & Roller

Material is 45# Steel Quenching and Plating.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.

Cutter

The material of blade is CR12.

With high strength, better hardenability and good wear resistance.

The carefully designed and manufactured cutters can maintain good cutting performance in long-term, high-intensity working environments, reducing the frequency of downtime and replacement due to cutter wear and damage, thereby reducing production costs and improving the company's production efficiency.
