    Aluminium Step Glazed Steel Tile Roll Forming Machine Chain Drive

    .Product Description

    After the equipment is started, the rolled metal sheet is first placed on the unwinder, smoothly unrolled and transported to the leveling device. The leveling device repeatedly rolls the sheet through multiple sets of leveling rollers, effectively eliminating the unevenness of the sheet during transportation or storage, ensuring that the sheet entering the subsequent forming process is in a flat state, laying the foundation for precise forming.

    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1220mm
    Roller Stations15Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed4m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    Able to accommodate a variety of metal coils of different specifications, including different widths, thicknesses and materials​

    Hydraulic Pump Station

    When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.


    The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.
    Feeding Table & Pre-Cutter

    In the conveying process, the feeding table accurately controls the conveying speed and position of the plate, and works closely with the subsequent leveling device, forming equipment, etc. It feeds the plate into the leveling process at a stable speed, ensuring that the plate is in a good conveying state before being leveled, laying the foundation for high-quality leveling operations.

    Shaft & Roller


    Material is 45# Steel Quenching and Plating.
    The processed rollers are smooth, hard and will not rust.

    Inside the glazed tile press, the shaft plays a vital role in support and transmission. Multiple shafts work together, like the beams of a building, to stably support the rollers and other components, ensuring that all components can maintain a stable position and posture during high-speed operation of the equipment, and will not be offset due to vibration or other external factors, thus ensuring the stability and reliability of the production process.

    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.

    The cutter's quick response and efficient cutting capabilities greatly improve production efficiency

    This equipment not only retains the beautiful and elegant characteristics of traditional glazed tiles, but also gives the product many advantages of modern metal materials. It is widely used in various construction projects that pursue beauty and quality, adding unique charm to building roofs and walls.
