    PPGI / GI Boltless Roof Roll Forming Machine

    Ask Lasest Price
    Brand Name : HC
    Model Number : HC45-333-1000
    Certification : CE
    Payment Terms : L/C, T/T
    Supply Ability : 20set per month
    Delivery Time : 20-30 work days
    • Product Details
    • Company Profile

    PPGI / GI Boltless Roof Roll Forming Machine

    Product Description
    Equipped with advanced CNC systems and precision-processed molds, the dimensional accuracy of the color steel tiles can be accurately controlled, so that the wave height, spacing and overall flatness of the tiles meet high standards. This ensures the tight splicing of the color steel tiles during installation and improves the overall aesthetics and waterproof performance of the building.


    Main Technical Parameters

    MaterialTypePPGI/GI
    Thickness0.3-0.6mm
    Width1000mm
    Roller Stations15Stations
    Roller & Shaft Material45# Steel Quenching and Plating
    Diameter of ShaftΦ70mm
    Cutter MaterialCR12
    Drive TypeChain Drive
    Speed15m/min
    Total Power5.5+5.5KW
    Voltage380V 50Hz 3Phases

    Working Flow
    Decoiling → Material Feeding → Roll Forming → Cutting → Collecting


    Component & Technical Parameters


    This part is used to support Coil.
    And make the coil in a rotary way.
    Bearing capacity: 5T
    Inner diameter: 470-530mm

    It automatically adjusts the unwinding speed according to the speed and demand of subsequent processes, achieving automation and continuity of the entire production process.


    Hydraulic Pump Station


    During the cutting process, the hydraulic pump station pushes the cutting tool to move quickly and forcefully, accurately cutting the formed floor decking according to the set length.

    Touch Screen Control Cabinet

    The control cabinet has two modes, automatic and manual modes.
    The unit length of the targeted sheet and quantity can be set in the touchscreen.
    The system is simple and easy to operate.

    The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.

    Feeding Table & Pre-Cutter

    The feeding table also has a certain buffering function. When there is a short speed fluctuation in the upstream uncoiler or downstream forming equipment, the feeding table can maintain the continuity of material transportation through its own buffering mechanism to avoid production stagnation or sheet damage caused by speed differences.


    Shaft & Roller

    Material is 45# Steel Quenching and Plating.
    The processed rollers are smooth, hard and will not rust.
    Will not leave any scratches on the sheet when working.

    Inside the molding machine, multiple shafts cooperate with each other to support the rollers and other components, ensuring that they maintain a stable position and posture during operation.

    Pressing Section & Cutter

    The material of blade is CR12.
    With high strength, better hardenability and good wear resistance.


    The automated production process is completed in one go from plate loading to finished product output, with a fast production speed, which can meet the large demand for color steel tiles for construction projects of different sizes. Compared with traditional production methods, it greatly shortens the production cycle and improves production efficiency.
