Product Description
The glazed tile pressing machine is a professional equipment
designed specifically for the production of glazed tiles. It
integrates advanced mechanical manufacturing technology and
automatic control technology, and can accurately process metal
coils, such as galvanized steel plates, color-coated steel plates,
etc., into new color-coated steel glazed tiles with the appearance
and performance of traditional glazed tiles.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm |
| Width | 1200mm |
| Roller Stations | 15Stations |
| Roller & Shaft Material | 45# Steel Quenching and Plating |
| Diameter of Shaft | Φ70mm |
| Cutter Material | CR12 |
| Drive Type | Chain Drive |
| Speed | 4m/min |
| Total Power | 5.5+5.5KW |
| Voltage | 380V 50Hz 3Phases |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
The uncoiler automatically adjusts the uncoil speed according to
the speed and demand of the subsequent process, realizing the
automation and continuity of the entire production process. This
collaborative operation can greatly improve production efficiency
and avoid production stagnation caused by improper coordination
between various equipment.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive
pressure, it can automatically adjust the pressure of the hydraulic
system to avoid damage to the equipment due to overload, thereby
improving the reliability and stability of the floor deck forming
machine.
The hydraulic pump station can also realize overload protection.
When the equipment encounters abnormal resistance or excessive
pressure, it can automatically adjust the pressure of the hydraulic
system to avoid damage to the equipment due to overload.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
The feeding table also has a certain buffering function. When there
is a short speed fluctuation in the upstream uncoiler or downstream
forming equipment, the feeding table can maintain the continuity of
material transportation through its own buffering mechanism to
avoid production stagnation or sheet damage caused by speed
differences.
Shaft & Roller
Material is 45# Steel Quenching and Plating.
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Inside the molding machine, multiple shafts cooperate with each
other to support the rollers and other components, ensuring that
they maintain a stable position and posture during operation.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
The reliability and durability of the cutter are also important
factors affecting production stability. Carefully designed and
manufactured cutters can maintain good cutting performance in
long-term, high-intensity working environments, reducing the
frequency of downtime and replacement due to cutter wear and
damage, thereby reducing production costs and improving the
company's production efficiency.
With its advanced technology, excellent performance and wide range
of applications, the glazed tile pressing machine provides the
construction industry with a highly innovative solution for the
production of roofing and wall materials, fully meeting the dual
pursuit of beauty and quality in modern architecture, and helping
the construction industry move towards a higher quality development
stage.
