Brand Name : | HC |
Model Number : | HC26-175-1050-1250 |
Certification : | CE |
Payment Terms : | L/C, T/T |
Supply Ability : | 20set per month |
Delivery Time : | 20-30 work days |
Product Description
With its advanced technology, excellent performance and wide range
of applications, the glazed tile pressing machine provides the
construction industry with a highly innovative solution for the
production of roofing and wall materials, fully meeting the dual
pursuit of beauty and quality in modern architecture, and helping
the construction industry move towards a higher quality development
stage.
Main Technical Parameters
Material | Type | PPGI/GI |
Thickness | 0.3-0.6mm | |
Width | 1250mm | |
Roller Stations | 11Stations | |
Roller & Shaft Material | 45# Steel Quenching and Plating | |
Diameter of Shaft | Φ70mm | |
Cutter Material | CR12 | |
Drive Type | Chain Drive | |
Speed | 4m/min | |
Total Power | 5.5+5.5KW | |
Voltage | 380V 50Hz 3Phases |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of glazed tiles, metal sheets are usually
supplied in the form of coils. The primary function of the uncoiler
is to smoothly and steadily unwind these tightly wound metal
sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive
pressure, it can automatically adjust the pressure of the hydraulic
system to avoid damage to the equipment due to overload, thereby
improving the reliability and stability of the floor deck forming
machine.
In the cutting process, the hydraulic pump station pushes the
cutting tool to move quickly and forcefully, accurately cutting the
formed floor deck to the set length.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
The feeding table also has a certain buffering function. When there
is a short speed fluctuation in the upstream uncoiler or downstream
forming equipment, the feeding table can maintain the continuity of
material transportation through its own buffering mechanism to
avoid production stagnation or sheet damage caused by speed
differences.
Shaft & Roller
Material is 45# Steel Quenching and Plating.
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
The glazed tile pressing machine is a professional equipment
designed specifically for glazed tile production. It combines
advanced mechanical manufacturing technology with automatic control
technology, and can accurately process metal coils, such as
galvanized steel plates, color-coated steel plates, etc., into new
color-coated steel glazed tiles with the appearance and performance
of traditional glazed tiles.
![]() |
